CREE Xlamp COB generation 18* 18 size 40 W COB CXA1830 80CRI 3000k 4000k 5000k
| Size | 17.85 x 17.85 mm |
|---|---|
| Product Options | High-CRI |
| Maximum Drive Current (Standard) | 1.4 A |
| Max Power (W) | 57 W |
| Light Output | 4500 - 6500 lm |
| Maximum Efficacy at Binning Conditions (lm/W) | 145 lm/W |
| Light Emitting Surface (LES) | 14 mm |
| Typical Forward Voltage | 36.4 V @ 800 mA |
| Maximum Reverse Current | 0.1 mA |
| Viewing Angle | 115 ° |
| Binning | 85°C ANSI (White) 2- and 4-Step EasyWhite® |
| Maximum ESD Withstand Voltage | 8000 V (HBM per Mil-Std-883D) |
| RoHS-Compliant | Yes |
| REACh-Compliant | Yes |
| UL-Recognized | Yes - Level 4 Enclosure Consideration |
|
|
