| Brand Name : | CREE |
| Model Number : | CXA1820-0000-000N00Q230G/CXA1820-0000-000N0HQ440G |
CREE Xlamp COB generation 18* 18 size 25 W COB CXA1820 80CRI 3000k 4000k 5000k for Track Light
| Size | 17.85 x 17.85 mm |
|---|---|
| Product Options | High-CRI |
| Maximum Drive Current (Standard) | 0.9 A |
| Max Power (W) | 38 W |
| Light Output | 1700 - 3800 lm |
| Maximum Efficacy at Binning Conditions (lm/W) | 149 lm/W |
| Light Emitting Surface (LES) | 12 mm |
| Typical Forward Voltage | 36.2 V @ 450mA |
| Maximum Reverse Current | 0.1 mA |
| Viewing Angle | 115 ° |
| Binning | 85°C ANSI (White) 2- and 4-Step EasyWhite® |
| Maximum ESD Withstand Voltage | 8000 V (HBM per Mil-Std-883D) |
| RoHS-Compliant | Yes |
| REACh-Compliant | Yes |
| UL-Recognized | Yes - Level 4 Enclosure Consideration |
|
|
