CREE Xlamp XHP70A 12v 3000k ,4000k,6500k application for wall pack ,car light and torch
| Size | 7 x 7 mm |
| Product Options | 6 V |
| 12 V | |
| High-CRI | |
| Maximum Drive Current (Standard) | 4.8 A (6 V) |
| 2.4 A (12 V) | |
| Max Power (W) | 29 W |
| Max Light Output (lm) | 4292 lm |
| Maximum Efficacy at Binning Conditions (lm/W) | 181 lm/W |
| Typical Forward Voltage | 5.6 V White @ 2100 mA (6 V) |
| 11.2 V @ 1050 mA (12 V) | |
| Viewing Angle | 125 ° |
| Binning | 85°C |
| ANSI (White) | |
| 2- 3- and 5-Step EasyWhite® | |
| Reflow Solderable | Yes JEDEC J-STD-020C-compatible |
| Thermal Resistance | 0.9 °C/W |
| RoHS-Compliant | Yes |
| REACh-Compliant | Yes |
|
|
